AR Coating | Anti-Reflective Coating |
ARM9 | 32-bit RISC CPU |
COB | Chip on Board. An assembly technology where integrated circuits are connected on a printed circuit board. |
COG | Chip on Glass. An assembly technology where integrated circuits are connected on a glass substrate. |
COF | Chip on Flex. An assembly technology where integrated circuits are connected on a flexible substrate. |
ECN | Electronic Component News |
ESD | Electrostatic Discharge |
FPC | Flexible Printed Circuit |
FSTN | Film compensated Super Twisted Nematic. A passive matrix LCD technology that offers greater sharpness and contrast than STN displays. |
GSTN | Grey STN. A grey Super Twisted Nematic LCD technology. |
HVAC | Heating, Ventilation and Air Conditioning |
I²C | Inter-Integrated Circuit. A two-wire low-speed serial bus. Also referred to as Two-Wire Interface. |
IP54 | International Protection Rating classifying protection against dust and water. |
ITO | Indium Tin Oxide. A transparent, conductive oxide used to generate grids across touch panels. |
LCD | Liquid Crystal Display |
LCM | Liquid Crystal Display Module. An LCD display module including backlight and electronics. |
LED | Light Emitting Diode |
LVDS | Low-Voltage Differential Signaling |
OCA | Optically Clear Adhesive |
ODM | Original Design Manufacturer |
OEM | Original Equipment Manufacturer |
PCAP | Projected Capacitive |
PCB | Printed Circuit Board |
PCI DSS | Payment Card Industry Data Security Standard. Worldwide standard for the security of card payments. |
POS | Point Of Sale. Refers to the hardware and software used in checkout systems. |
SPI | Serial Peripheral Interface Bus. A four-wire serial communication protocol named by Motorola. |
STN | Super Twisted Nematic. A monochrome passive matrix LCD technology which provides higher contrast than TN displays. |
TFT | Thin Film Transistor. An active matrix LCD technology. |
TN | Twisted Nematic. A monochrome passive matrix LCD technology. |
USB | Universal Serial Bus |
VGA | Video Graphics Array. Displays a resolution of 640x480. |
QVGA | Quarter Video Graphics Array. Displays a resolution of 320x240. |
Birefringence
Splitting a light wave into two unequally reflected waves resulting in a rainbow effect.
Crystal Touch
Ocular's line of projected capacitive touch panels.
Gesturing
In addition to sensing the location of a single finger, the touch panel can also detect if a two finger zoom/pinch/rotate is in progress. The controller only reports the location of the first finger but can detect if a two finger zoom/pinch/rotate is in progress.
Low-Viz ITO
A unique Ocular design that virtually eliminates the visible Indium Tin Oxide traces on touch panels.
Optical Bonding
A manufacturing technique for eliminating the air gap between displays, cover lens and touch panels, improving visibility and durability. Ocular has licensed the use of DuPont™ Vertak® direct bonding display technology.
Projected Capacitive (PCAP)
A touch panel technology that determines touch location by sensing changes in electric field across the panel, caused by finger proximity. This contrasts with resistive touch technology, which utilizes physical pressure on the panel surface. Projected Capacitive (PCAP) touch panels are more reliable and result in superior optical clarity than resistive touch panels.
Single Touch
Only one location, i.e. finger, can be identified by the controller. If more than one finger is placed on a single touch panel, the controller will accept only one touch point: the midpoint between the two fingers.
Touch Screen
User interface that is part of a full touch display assembly; includes a TFT and touch panel/sensor as part of the stack-up.
Touch Panel
A standalone touch sensor.
Transmissivity/Transmittance
The percentage of visible light that passes through glass.
TRUE Multi-Touch
The controller can report the location of more than one finger simultaneously and create separate demands for each touch point. Ocular’s TRUE Multi-Touch PCAP touch panels can report up to 16 different touch points simultaneously.
